Replacement doors

Walk-in cooler and freezer doors, matched to your opening

Updated

Retrofit plug doors and complete door-and-frame replacements for the walk-in you already own, in standard sizes or made to your opening, plus manual or electric sliding doors for openings where a swing door cannot work.

Quick answer

Frigid Coolers sells walk-in cooler doors and walk-in freezer doors (insulated commercial refrigeration doors) as retrofit plug doors and complete door-and-frame replacements: small plug doors 34″ × 76″ to 38″ × 76″, large plug doors 48″ × 78″ to 60″ × 78″, and sliding doors from 4′ × 7′ to 10′ × 10′, or made to any opening. They fit most makes of walk-in and come with all the components needed for installation.

When you request a quote or place an order, tell us whether it is a cooler or a freezer and give the walk-through opening: width, height and depth. Freezer doors and frames come with a perimeter heater wire; cooler doors do not.

Three door families

Standard sizes, or made to your opening

We can meet any size opening. Call for other sizes. These are the standard sizes on the shelf.

Replacement doors for walk-in coolers and freezers, standard sizes
DoorStandard sizes (W × H)Hinges and hardwareInsulation
Small plug door34″ × 76″ · 36″ × 76″ · 38″ × 76″2 cam-lift hinges, latch, glow-in-the-dark inside release handle4″ · R-29.2 cooler / R-34 freezer
Large plug door48″ × 78″ (2 hinges) · 54″ × 78″ (3 hinges) · 60″ × 78″ (2 hinges)Heavy-duty strap hinges, heavy-duty latch, glow-in-the-dark inside release handle4″ · R-29.2 cooler / R-34 freezer
Sliding door, manual or electric4′×7′ · 5′×7′ · 6′×7′ · 6′×8′ · 7′×7′ · 7′×8′ · 8′×8′ · 8′×10′ · 9′×10′ · 10′×10′Heavy-duty adjustable track, two 4-wheel bearing trolleys, 8¼″ chrome-plated outside pull, recessed inside pull4″ · R-29.2 cooler / R-34 freezer

All doors: 26 gauge stucco-embossed Acrylume inside and out, 2009 EISA compliant insulation. Specify cooler or freezer and give the walk-through opening (width, height and depth) when you ask for a quote.

Small and large

Retrofit plug doors and frames

A complete door and frame that sets into the opening of the walk-in you have. The small door is the standard personnel door; the large door takes carts, racks and pallet traffic through in one movement.

  • Wooden door frame encased in metal: heavy-duty on the large doors.
  • 26 gauge stucco-embossed Acrylume on the interior and exterior of door and frame.
  • 4″ insulation with an EISA-approved R-value of R-29.2 for coolers and R-34 for freezers.
  • Inside casing door frame to secure the exterior door frame.
  • Hardware: cam-lift hinges on the small doors, heavy-duty strap hinges and a heavy-duty latch on the large ones, and a glow-in-the-dark inside release handle on all of them. You cannot get locked in, even if the latch is padlocked.
  • Perimeter door gasket for a positive seal around the frame, and a door sweep across the bottom to seal to the floor or threshold.
  • Freezer doors and frames are equipped with a perimeter heater wire connected to a 2″ × 4″ electrical junction box (115 V).
Frigid Coolers drawing of a replacement plug door and frame fitted into an existing cooler wall, with callouts identifying the existing frame and the new plug door and frame
Retrofit plug door and frame set into an existing cooler or freezer wall. The callouts show how the inside casing secures the exterior frame. More views →
Manual or electric

Horizontal sliding doors for openings that cannot swing

Frigid’s cooler or freezer horizontal single-leaf sliding doors are used for personnel and material-handling traffic where space restricts a swing-type door. Suitable for interior and exterior applications on coolers, freezers and food processing facilities that need a larger door for pallet or forklift traffic. Electric operation is also available. Full sizes, wall and height checks, hardware and drawings are on the walk-in sliding doors page.

  • 4″ insulation, R-29.2 cooler / R-34 freezer, 26 gauge stucco-embossed Acrylume inside and out.
  • Outside casing of 1⅝″ × 12″ metal clad with a bubble neoprene gasket on three sides; inside casing of 1⅝″ × 12″ metal clad top and 6″ sides.
  • Heavy-duty track, adjustable in and out, up and down, with two 4-wheel bearing trolleys for the door to glide on, a completely assembled track system for each installation, and a cover for the track.
  • Handles and stops: outside chrome-plated 8¼″ pull handle, inside recessed pull handle, front die-cast door stop and rear door stop bumper.
  • Bottom detail: trailer aluminum edge 4″ high with a 3″ wedge, rear floor guide roller and a double neoprene bottom sweep gasket.
  • Wall channel: 4″ PVC channel for a 4″ wall, or a metal channel matched to the wall thickness for wider doors.
  • Freezer doors and frames are equipped with a perimeter heater wire connected to a 2″ × 4″ electrical junction box (115 V).
Frigid Coolers drawing of a walk-in sliding door hung on an overhead track with its frame and floor guides
Walk-in sliding door on its overhead track, with frame and floor guides. Manual or electric operation. More views →
Options

Finish options

  • 26 gauge white stucco-embossed galvanized steel in place of Acrylume.
  • 24 gauge 304 grade stainless steel, #3 finish.
  • Aluminum diamond-tread kick plates, interior and exterior.
  • View windows in plug doors, different sizes available.
Diagnose it first

Signs the door is costing you money

A door that no longer seals is usually the largest single energy leak in a walk-in, and replacing it costs a fraction of replacing the box.

  • Frost or ice around a freezer frame: warm, humid air is getting in and freezing.
  • Sweating on a cooler door or the panel beside it.
  • A gasket that stays flat instead of springing back, or that is split, torn or pulling away.
  • Compressor runtime creeping up for the same load and the same weather.
What to send us for a quote. Cooler or freezer; the walk-through opening (width, height and depth); which way the door swings or slides; and two or three photographs: the full door, the hinge side and the gasket.
Straight answers

Walk-In Cooler & Freezer Doors FAQ

What is a refrigeration door?

A refrigeration door, also called a refrigerated door, is the insulated door and frame of a walk-in cooler, walk-in freezer or cold room. Ours have 4″ insulation, R-29.2 on a cooler and R-34 on a freezer, a perimeter gasket and a bottom sweep, and freezer frames carry a 115 V perimeter heater wire. We sell them as retrofit plug doors, complete door-and-frame replacements and manual or electric sliding doors, in standard sizes or made to your opening, for most makes of walk-in.

What is the difference between a walk-in cooler door and a freezer door?

The heater. A walk-in freezer door and its frame carry a perimeter heater wire connected to a 2″ × 4″ electrical junction box (115 V), so the frame does not ice up and freeze the door shut; a cooler door does not need one. The insulation is the same 4″ thickness, rated R-29.2 on a cooler door and R-34 on a freezer door.

Everything else is the same for cooler and freezer: the standard sizes (small plug doors 34″ × 76″ to 38″ × 76″, large plug doors 48″ × 78″ to 60″ × 78″, sliding doors 4′ × 7′ to 10′ × 10′), 26 gauge stucco-embossed Acrylume inside and out, and on the plug doors the perimeter gasket, the bottom sweep and the glow-in-the-dark inside release handle. Tell us cooler or freezer and the walk-through opening (width, height and depth), and we quote the matched door and frame.

Do you sell commercial freezer doors?

Yes. Our commercial freezer doors are insulated doors and frames for walk-in freezers, freezer rooms and cold storage: 4″ insulation rated R-34, and a 115 V perimeter heater wire in every freezer frame so it does not ice up. They come as retrofit plug doors, complete door-and-frame replacements or manual or electric sliding doors, from a 34″ × 76″ plug door up to a 10′ × 10′ sliding door, or made to your opening. Commercial cooler doors are the same build without the heater wire, rated R-29.2. Send the walk-through opening (width, height and depth) and tell us cooler or freezer.

Do you sell insulated cooler doors, cold room doors and industrial freezer doors?

Yes. Every door we sell is an insulated cooler or freezer door with its frame, for a walk-in cooler, walk-in freezer, cold room or freezer room: 4″ insulation, R-29.2 on a cooler and R-34 on a freezer, 26 gauge stucco-embossed Acrylume inside and out, a perimeter gasket and a bottom sweep, and a 115 V perimeter heater wire on every freezer frame so it does not ice up.

For industrial cooler and freezer doors in cold storage with carts, racks, pallets or forklifts, the large plug doors go up to 60″ × 78″ and the manual or electric sliding doors up to 10′ × 10′, suitable for interior and exterior applications on coolers, freezers and food processing facilities. Any other opening is made to order: send the walk-through opening (width, height and depth), tell us cooler or freezer, and we quote a matched door and frame.

Do you sell replacement glass doors for walk-in coolers?

Yes. We supply replacement glass doors on their own for existing walk-in coolers, walk-in freezers and beer caves, so the box can stay when the glass doors wear out: torn gaskets, failed heaters that let the glass fog or frost, hinges that no longer close the door. Text photos of the doors and the opening sizes to 954-237-6753. If the job adds doors, check the refrigeration at the same time, because more glass means more heat load. New glass door runs are on our glass door walk-in coolers page.

Will a replacement door fit my walk-in?

Our retrofit plug doors and replacement doors & frames fit most makes of walk-in and come with all the components needed for installation. Give us the walk-through opening (width, height and depth) and tell us cooler or freezer. Measure the frame opening, not the worn door.

What sizes do walk-in cooler and freezer doors come in?

Small plug doors: 34″ × 76″, 36″ × 76″ and 38″ × 76″. Large plug doors for carts, racks and pallets: 48″ × 78″, 54″ × 78″ and 60″ × 78″. Sliding doors, manual or electric: 4′ × 7′ up to 10′ × 10′. All have 4″ insulation, R-29.2 on a cooler door and R-34 on a freezer door, and any other size opening is made to order.

How do I measure a walk-in door for replacement?

Measure the frame opening, not the worn door: the walk-through width, the height, and the depth of the opening. Tell us cooler or freezer and which way the door swings or slides, and send two or three photographs: the full door, the hinge side and the gasket. That is enough to quote a matched door and frame.

When should a walk-in door be replaced?

When it no longer seals. The signs: frost or ice around a freezer frame, sweating on a cooler door or the panel beside it, a gasket that stays flat or is split, torn or pulling away, and compressor runtime creeping up for the same load and the same weather. A door that leaks is usually the largest single energy leak in a walk-in, and replacing the door and frame costs a fraction of replacing the box.

What parts come with a walk-in freezer door?

Every walk-in freezer door we sell comes as a complete door and frame with all of its parts: the door with 4″ insulation rated R-34 and 26 gauge stucco-embossed Acrylume inside and out, the wooden door frame encased in metal, the inside casing that secures the exterior frame, the perimeter door gasket, the bottom sweep, the hinges (2 cam-lift hinges on the small doors, heavy-duty strap hinges on the large ones), the latch, the glow-in-the-dark inside release handle, and the perimeter heater wire in the door and frame, connected to a 2″ × 4″ electrical junction box (115 V). A walk-in cooler door comes with the same parts without the heater wire, rated R-29.2.

A sliding freezer door comes with its heavy-duty adjustable track, two 4-wheel bearing trolleys and a track cover, an 8¼″ chrome-plated outside pull and a recessed inside pull, the door stops, a rear floor guide roller, a double neoprene bottom sweep gasket and the same heater wire. When an old freezer door has a split gasket or a frame that ices up, a matched door and frame replaces all of those parts at once and costs a fraction of replacing the box: send the walk-through opening (width, height and depth), which way it swings or slides, and photos of the full door, the hinge side and the gasket.

What is a plug door?

A door whose insulated slab sets into the opening rather than lying flat against it, with a perimeter gasket that seals all the way around the frame and a sweep across the bottom to the floor or threshold. It is the standard walk-in door format because that geometry seals and stays sealed as the gasket ages. Ours come as a complete door and frame, with an inside casing that secures the exterior frame.

When should I use a sliding door instead of a swing door?

When space restricts the use of a swing-type door, or when the traffic is pallets and forklifts and you need a larger opening. Sliding doors are suitable for interior and exterior applications on coolers, freezers and food processing facilities. Manual is standard; electric operation is also available.

Are freezer doors heated?

Yes. Freezer doors and frames are equipped with a perimeter heater wire connected to a 2″ × 4″ electrical junction box (115 V), so the frame does not ice up and freeze the door shut. Cooler doors do not need it, which is why we ask cooler or freezer before quoting.

Can I get stainless steel, or a window?

Both. 24 gauge 304 grade stainless steel in a #3 finish, or 26 gauge white stucco-embossed galvanized steel, in place of the standard Acrylume; aluminum diamond-tread kick plates inside and out; and view windows in different sizes.

Can a walk-in door be locked, and can I get locked inside?

The latch can be padlocked from outside, and you still cannot get locked in: every plug door carries a glow-in-the-dark inside release handle that opens the door from inside, even when someone padlocks the latch from outside.

Do you make other sizes?

Yes. The standard sizes are what is on the shelf; we can meet any size opening. Call with the walk-through opening and we will quote it.

Keep the box. Replace the door.

Send the opening (width, height, depth), tell us cooler or freezer, and add a couple of photographs. You get a matched door and frame quoted against your opening.
